Alko BM 5001 R-III Petrol Scythe Mower

AL-KO BM 5001 R-III petrol scythe mower

The AL-KO BM 5001 R-III is a specialist self-propelled petrol scythe mower for managing tall grass, meadow plants, nettles and dense non-woody vegetation in paddocks, orchards, wild gardens, forage areas and other natural ground.

Unlike a conventional rotary lawn mower, it uses a reciprocating 102cm sickle cutter bar. The blade moves backwards and forwards to cut vegetation close to the base, leaving the material behind in longer swaths rather than finely shredding or collecting it.

The wide cutter bar and forward-and-reverse wheel drive make the BM 5001 R-III suitable for larger natural areas of up to approximately 2,500m², depending on the height, density and moisture content of the vegetation and the condition of the terrain.

AL-KO BM 5001 R-III at a glance

• Manufacturer: AL-KO
• Brand: solo® by AL-KO
• Model: BM 5001 R-III
• Article number: 127469
• GTIN-13: 4003718058628
• Product range: Comfort pro
• Best suited to: meadows, paddocks, orchards and natural grass areas
• Suggested maximum working area: up to approximately 2,500m²
• Cutting width: 102cm / 40in
• Cutter type: reciprocating ESM sickle cutter bar
• Cutting-height range: approximately 25–60mm
• Engine: Briggs & Stratton 625 EXi
• Engine displacement: 150cc
• Transmission: one forward and one reverse gear
• Wheel drive: independently switchable
• Cutter-bar drive: independently switchable
• Tyres: 13in pneumatic agricultural-tread tyres
• Handle: height-adjustable and vibration-damped
• Fuel-tank capacity: approximately 0.8 litres
• Net weight: approximately 58kg
• Grass collection: no
• Mulching: no

Is the AL-KO BM 5001 R-III right for you?

Choose the BM 5001 R-III if:

• You need to cut tall grass that is unsuitable for a normal rotary lawn mower
• You maintain a large meadow, paddock, orchard or natural garden
• You want to leave the cut vegetation in longer lengths for gathering or forage use
• You need a wide 102cm cut for efficient coverage of open areas
• You need reverse gear for manoeuvring around field edges and obstacles
• You want the wheel drive and cutter-bar drive to operate independently
• You need adjustable cutter-bar shoes for varying ground conditions
• You value access to specialist dealer setup and workshop support

Consider another machine if:

• You want a short, even, formal-lawn finish
• You need the machine to collect or mulch the cut material
• The area contains substantial woody brambles, thick rushes or saplings
• Your access or storage space is narrower than the 102cm cutter bar
• You need a lightweight machine that can be lifted easily
• You mainly need to work around fences, trees and confined obstacles
• You want the latest BM 5001 R-IV rather than previous-generation R-III stock

Why Masseys recommends the AL-KO BM 5001 R-III

Masseys recommends the BM 5001 R-III to landowners who need to manage large areas of tall meadow grass while retaining the cut material in longer lengths rather than shredding it.

The 102cm cutter bar covers open ground efficiently, while the reverse gear is a significant advantage over the narrower BM 875 III when the work involves field boundaries, orchard rows or repeated changes of direction.

The ability to engage the cutter bar and wheel drive independently also improves control. The machine can be moved with the cutting mechanism stopped when the controls and procedures in the operator manual are followed.

This is not the best recommendation for predominantly woody vegetation. Where the area contains extensive brambles, rushes, mixed scrub or saplings, Masseys would normally recommend comparing it with the Weibang Velocity 76 FBM field-and-brush mower or the Weibang Velocity 68 WFP flail mower.

How the 102cm sickle cutter bar works

The BM 5001 R-III uses a reciprocating cutter bar rather than a high-speed rotary blade. Moving blade sections pass against fixed fingers to cut the vegetation near its base.

This method is suitable for tall grass, nettles, meadow plants and other herbaceous vegetation. Because the material is cut rather than finely shredded, it is left behind in longer swaths and can be gathered afterwards where required.

The 102cm cutter bar uses a specially hardened ESM blade designed for durability. Edge protection helps reduce damage if the end of the bar contacts a boundary or obstacle.

Before mowing, inspect the working area and remove stones, wire, branches and other objects that could damage the blade or create a hazard.

Continuously adjustable cutting height

The cutter-bar shoes allow the working height to be adjusted continuously between approximately 25mm and 60mm.

A higher setting can help protect the bar on uneven ground, while a lower position allows vegetation to be cut closer to the base where the ground conditions permit.

Both sides should be adjusted consistently and the procedure in the supplied operator manual must be followed.

Forward and reverse wheel drive

The self-propelled wheel drive has one forward and one reverse gear.

Forward drive reduces the effort required to move the approximately 58kg machine across the working area. Reverse gear improves manoeuvrability when working near boundaries, around large obstacles or at the end of a mowing run.

The BM 5001 R-III remains a wide and substantial machine. The reverse gear does not remove the need for careful route planning, suitable access and secure footing.

Independent wheel and cutter-bar controls

The wheel drive and cutter-bar drive can be engaged and disengaged independently.

This allows the machine to be repositioned without the cutting mechanism operating when the controls and safety procedures in the operator manual are followed.

Stop the cutting mechanism and engine before clearing vegetation, inspecting the blade or carrying out maintenance. Isolate the spark plug where directed by the manufacturer.

150cc Briggs & Stratton engine

The BM 5001 R-III article 127469 uses a 150cc Briggs & Stratton 625 EXi four-stroke petrol engine.

The engine powers both the reciprocating cutter bar and the self-propelled wheel drive. It uses recoil starting and has a fuel-tank capacity of approximately 0.8 litres.

Fresh petrol, the correct four-stroke engine oil and scheduled servicing are essential. Follow the AL-KO and Briggs & Stratton documentation for starting, refuelling, transport, maintenance and seasonal storage.

13in agricultural-tread tyres

The two 13in pneumatic tyres use a wide agricultural-style tread intended to provide traction across meadows and uneven natural ground.

The machine has an approximate wheel-track width of 55cm. The relatively short distance between the wheels and cutter bar helps improve manoeuvrability and placement of the cut vegetation.

Tyre pressures should be checked regularly and maintained according to the operator manual.

Working on slopes and uneven ground

The BM 5001 R-III is designed for natural ground, meadow edges and uneven terrain. Masseys’ existing product information references slopes of up to approximately 20°.

Any slope figure remains subject to the supplied operator manual and the actual working conditions. A surface can be unsafe at a lower angle where it is wet, loose, rutted, unstable or obstructed.

• Inspect the complete area before starting
• Remove stones, wire and hidden obstacles
• Do not operate on wet or unstable slopes
• Wear suitable protective footwear and clothing
• Keep people and animals away from the working area
• Take additional care when changing direction or reversing

Grass placement and movable deflector

The movable grass deflector helps guide the cut vegetation away from the cutter-bar cover, reducing material build-up on top of the machine.

The BM 5001 R-III does not collect the cut material. It must be left in place, gathered manually or handled afterwards using appropriate machinery.

Important limitations to consider

• The machine weighs approximately 58kg
• The cutter bar is 102cm wide
• It does not collect or mulch vegetation
• It is not intended to produce a short formal-lawn finish
• It is primarily designed for grass and herbaceous vegetation rather than substantial woody growth
• The handlebar is height-adjustable but does not fold
• The cutter bar requires inspection, adjustment, cleaning and lubrication
• Suitable ramps or loading arrangements may be required for transport

Compare rough-ground mowing options

Browse the wider Masseys garden machinery range or view other mowing equipment available from Masseys.

AL-KO BM 5001 R-III technical specifications

Warranty, setup and aftersales support

The current Masseys listing states a two-year standard domestic warranty, a five-year extended domestic warranty subject to annual servicing, and 90-day commercial cover.

Because the BM 5001 R-III has now been superseded by the R-IV, confirm the exact warranty documentation supplied with the physical article-127469 machine before purchase.

Masseys can advise on assembly, pre-delivery inspection and setup. Correct cutter-bar installation and adjustment are especially important on a 102cm scythe mower.

Ongoing support is available through the Masseys garden-machinery workshop. Learn more about garden machinery servicing and repairs.

Masseys also supplies Aspen four-stroke alkylate petrol and other engine oils and fuel products for suitable garden machinery. Always follow the engine manufacturer’s fuel and oil requirements.

Frequently asked questions

What is the BM 5001 R-III designed to cut?

It is designed primarily for tall grass, nettles, meadow plants, forage grass and other dense non-woody vegetation in natural areas.

Can it cut brambles and saplings?

It may cut light, soft or young growth, but it should not be treated as a dedicated woody-brush or sapling mower. A field-and-brush or flail mower is normally more appropriate for substantial brambles, rushes or saplings.

Does it collect the grass?

No. The cutter bar leaves the vegetation behind in longer swaths. The material must be left in place or gathered afterwards.

Does it have reverse gear?

Yes. The BM 5001 R-III has one forward and one reverse gear, improving manoeuvrability around field edges and obstacles.

How wide is the cutter bar?

The ESM cutter bar is approximately 102cm, or 40 inches, wide.

What is the cutting-height range?

The cutter-bar shoes provide continuous adjustment from approximately 25mm to 60mm.

How heavy is the machine?

The BM 5001 R-III has an approximate net weight of 58kg. Suitable ramps or transport arrangements may be needed when loading it into a vehicle.

Is it suitable for an ordinary garden lawn?

It can cut grass, but it is not designed to produce the short, even finish of a conventional rotary or cylinder lawn mower. Its primary purpose is managing tall and natural vegetation.

Can it be used on slopes?

The existing product information references slopes of up to approximately 20°. The operator manual, ground stability, moisture, obstacles and secure footing must always take priority.

What is the difference between the BM 5001 R-III and BM 875 III?

The BM 5001 R-III has a wider 102cm cutter bar and both forward and reverse gears. The BM 875 III has a narrower 87cm cutter bar and forward drive only.

Is this the BM 5001 R-III or R-IV?

This listing is for the previous-generation BM 5001 R-III, article 127469 and GTIN 4003718058628. It should not be confused with the current R-IV, which uses a different engine and product specification.

Can Masseys assemble and service the machine?

Masseys can advise on assembly and setup and operates an in-house workshop for servicing, repairs and warranty support.
